Meet the unique individual needs of smartphone users
provide industry-leading high-quality imaging performance for smartphone cameras
provide industry-leading high-quality imaging performance for smartphone cameras
Quality Imaging
Great night photography
Excellent night vision captures the soul of the night
Shot on a device with the SC500CS sensor in Puxi, Shanghai
Better SNR and DR greatly elevates image quality
SC500CS
Competitor Similar Products
Read Noise Reduce
(e-)
SC500CS
Competitor Similar Products
Dynamic Range Promote
(dB)
SC800CS
Competitor Similar Products
FPN Reduce
(e-)
SC800CS
Competitor Similar Products
Max SNR Promote
(dB)
With the PDAF technology, mesmerizing moments are captured instantly
PDAF Technology
XS Series
| Product Series | PN | Select Resolution | Select Optical Format | Pixel Size | Select Shutter Type | Select whether to have HDR | Pixel Array | Max Frame Rate | CRA | Interface | Package | Download | Contact Us |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SmartClarity®-2 | NewSC580XS | 50MP | 1/1.28" | 1.22μm | Rolling | Yes | 8192Hx6144V | 30fps | 36.9° | MIPI | COB/RW | - | Contact Sales |
| SmartClarity®-2 | SC550XS | 50MP | 1/1.56" | 1.0μm | Rolling | Yes | 8208Hx6160V | 30fps | 36.65° | MIPI | COB/RW | Contact Sales | |
| SmartClarity®-2 | SC520XS | 52MP | 1/2.42" | 0.7μm | Rolling | Yes | 8784Hx6064V | 15fps | Tele:17.9° Wide:35.3° | MIPI | COB/RW | Contact Sales |
HS Series
| Product Series | PN | Select Resolution | Select Optical Format | Pixel Size | Select Shutter Type | Select whether to have HDR | Pixel Array | Max Frame Rate | CRA | Interface | Package | Download | Contact Us |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SmartClarity®-XL | NewSC130HS | 13MP | 1/3.06" | 1.116μm | Rolling | Yes | 4208Hx3120V | 60fps | 33.69° | MIPI | COB/RW | - | Contact Sales |
| SmartClarity®-XL | SC140HS | 14MP | 1/2.64" | 1.224μm | Rolling | Yes | 4576H×3168V | 30fps | 35.77° | MIPI | COB/RW | - | Contact Sales |
CS Series
| Product Series | PN | Select Resolution | Select Optical Format | Pixel Size | Select Shutter Type | Select whether to have HDR | Pixel Array | Max Frame Rate | CRA | Interface | Package | Download | Contact Us |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SmartClarity®-3 | NewSC1620CS | 16MP | 1/3.09" | 1.0μm | Rolling | 4672Hx3512V | 60fps | 34° | MIPI | COB/RW | - | Contact Sales | |
| SmartClarity®-3 | NewSC5000CS | 50MP | 1/2.5'' | 0.702μm | Rolling | Yes | 8224Hx6176V | 15fps | 35.7° | MIPI | COB/RW | - | Contact Sales |
| DSI-2 | SC080CS | QVGA | 1/20" | 2.24μm | Rolling | 248Hx328V | 30fps | 16.68° | SPI | CSP9 | Contact Sales | ||
| SmartClarity®-3 | SC202CS | 2MP | 1/5.1" | 1.75μm | Rolling | 1608Hx1208V | 30fps | 30.76° | MIPI | CSP/COB/RW | - | Contact Sales | |
| DSI-2 | SC201CS | 2MP | 1/5.1" | 1.75μm | Rolling | 1608Hx1208V | 30fps | 31.5° | MIPI | CSP/COB/RW | Contact Sales | ||
| SmartClarity®-3 | SC521CS | 5MP | 1/5" | 1.12μm | Rolling | 2600Hx1952V | 30fps | 31.9° | MIPI | COB/RW | - | Contact Sales | |
| SmartClarity®-2 | SC501CS | 5MP | 1/5" | 1.12μm | Rolling | 2600Hx1952V | 30fps | 31.87° | MIPI | COB/RW | Contact Sales | ||
| SmartClarity®-2 | SC520CS | 5MP | 1/5" | 1.12μm | Rolling | 2600Hx1960V | 30fps | 31.9° | MIPI | CSP/COB/RW | Contact Sales | ||
| SmartClarity®-2 | SC820CS | 8MP | 1/4" | 1.12μm | Rolling | 3280Hx2464V | 30fps | 32.55° | MIPI | COB/RW | Contact Sales | ||
| SmartClarity®-3 | SC1320CS | 13MP | 1/3.06" | 1.12μm | Rolling | 4224Hx3134V | 30fps | 33.69° | MIPI | COB/RW | Contact Sales | ||
| SmartClarity®-2 | SC1600CS | 16MP | 1/3.06" | 1.0μm | Rolling | 4656Hx3096V | 60fps | 33.98° | MIPI | COB/RW | Contact Sales |
